CEM150 series flange mounted

15 kV HVSC Coupler

CEM150 flange mounted

Design: flange mounted coupler (plug & receptacle)
Contact assignment: 3 phase, 1 ground, 1 pilot, with/without micro switch
Rated voltage: 15 kV 3 AC
Rated withstand voltage: 50 kV (1 min) dry
Rated current: 500 A
Short circuit current: 38 kA RMS
Frequency: 50 – 60 Hz
Protection class: IP 67H
Ambient temperature: -30 °C to +45 °C
Shock resistance: IK 10
Sealing: EPDM and potting compound
Cable cross section / ø: 35 – 240 mm² / 21 – 89 mm
Material: anodized, heat-treated aluminum
Surface treatment: epoxy powder coating in blue color (RAL 5015)
Dimensions P / R (L x ø): 229 x 311 mm / 210 x 311 mm
Weight Plug / Receptacle: 14,5 kg / 12,3 kg
USP: designed in accordance to IEC, ISO, IEEE 80005-1 (HVSC)

C-Coupler-Series

Product: Live current insulated cover
Features: Possibility of applying a voltage to the connector even when not plugged in
Design: Male and female design for CEM150 coupler series
  • The strain relief entrance fittings are included with the CEM150 coupler series.
  • The entrance fitting gasket kits are normally not included with the C coupler series. For Europe, there are exceptions, so this point must be requested on a case by case basis.
  • The termination kits must be ordered separately with the CEM150 series.

The termination kit for preparing the conductors consists of: emery paper, shrink tubing, adhesive strap, copper contact tape, contact spring, resin for pressure relief and solvent as well as cleaning cloths.
