CEM150 series cable mounted

15 kV HVSC Coupler

CEM150 cable mounted

Design: cable mounted coupler (plug & receptacle)
Contact assignment: 3 phase, 1 ground, 1 pilot
Rated voltage: 15 kV 3 AC
Rated withstand voltage: 50 kV (1 min) dry
Rated current: 500 A
Short circuit current: 38 kA RMS
Frequency: 50 – 60 Hz
Protection class: IP 67H
Ambient temperature: -30 °C to +45 °C
Shock resistance: IK 10
Sealing: EPDM and potting compound
Cable cross section / ø: 35 – 240 mm² / 21 – 89 mm
Material: anodized, heat-treated aluminum
Surface treatment: epoxy powder coating in blue color (RAL 5015)
Dimensions P / R (L x H): 622 x 267  mm / 686 x 292 mm
Weight Plug / Receptacle: 17  kg / 17 kg
USP: designed in accordance to IEC, ISO, IEEE 80005-1 (HVSC)

C-Coupler-Series

Product: Live current insulated cover
Features: Possibility of applying a voltage to the connector even when not plugged in
Design: Male and female design for CEM150 coupler series
  • The strain relief entrance fittings are included with the CEM150 coupler series.
  • The entrance fitting gasket kits are normally not included with the C coupler series. For Europe, there are exceptions, so this point must be requested on a case by case basis.
  • The termination kits must be ordered separately with the CEM150 series.
  • Potting compound is required for the CEM150 coupler series.

The termination kit for preparing the conductors consists of: emery paper, shrink tubing, adhesive strap, copper contact tape, contact spring, resin for pressure relief and solvent as well as cleaning cloths.

Sketch Outer cable diameter Article number
(mm) (in)
21 – 47 0.820 – 1.870 C150F3029
48 – 60 1.880 – 2.370 C150F3030
61 – 69 2.380 – 2.750 C150F3031
70 – 89 2.760 – 3.500 C150F3032
Suitable for C80, C150, CEM 150 and C250 connector and coupler series
Cable diameter Article number
(mm) (in)
20,8 – 22,1 0.82 – 0.87 C150F3004
22,4 – 23,9 0.88 – 0.94 C150F3005
24,1 – 25,7 0.95 – 1.01 C150F3006
25,9 – 26,9 1.02 – 1.06 C150F3007
27,2 – 28,4 1.07 – 1.12 C150F3008
28,7 – 31,8 1.13 – 1.25 C150F3009
32,0 – 34,8 1.26 – 1.37 C150F3010
35,0 – 38,1 1.38 – 1.50 C150F3011
38,4 – 41,1 1.51 – 1.62 C150F3012
41,4 – 44,5 1.63 – 1.75 C150F3013
44,7 – 47,5 1.76 – 1.87 C150F3014
47,8 – 50,8 1.88 – 2.00 C150F3015
Cable diameter Article number
(mm) (in)
51,1 – 53.8 2.01 – 2.12 C150F3016
54,1 – 57,2 2.13 – 2.25 C150F3017
57,4 – 60,2 2.26 – 2.37 C150F3018
60,5 – 63,5 2.38 – 2.50 C150F3019
63,8 – 66,5 2.51 – 2.62 C150F3020
66,8 – 69,9 2.63 – 2.75 C150F3021
70,1 – 72,9 2.76 – 2.87 C150F3022
73,2 – 76,2 2.88 – 3.00 C150F3023
76,5 – 79,2 3.01 – 3.12 C150F3024
79,5 – 82,6 3.13 – 3.25 C150F3025
82,8 – 85,6 3.26 – 3.37 C150F3026
85,9 – 88,9 3.38 – 3.50 C150F3027
Suitable for C80, C150, CEM150 and C250 coupler series
Pay attention: The sealing inserts normally must be ordered separately!
