Loop Joints
Cable Joints
LoviSil® Loop Joints
| Application: | direct installation of 2 cables in a stop end module becoming a loop |
| Type of cable: | universal use for paper-insulated (PILC, PICAS) and polymeric cables (XLPE, EPR) |
| Advantages: | – less excavation work – less cable needed – sub station redundant – shorter assembly time |
| Connection possibilities: | – single and multi-core cables – small and large cable cross sections – armored and non-armored cables |
| Rated voltage: | 12 kV up to 36 kV |
| Conductor cross section: | 70 to 1000 mm² |
| Outer cable diameter: | max. up to 87 mm |
| Material enclosure joint: | ABS (red) |
| Filling resin installation enclosure: | silicone, liquid (LoviSil®) |
| Filling resin joint: | polyurethane (2-component PUR-resin) |
| Water pressure test: | 2 bar |
| Modular design: 1. module 2. module 3. module |
flexible and universal modular system basis module (hardware components for joint) resin module (Protolin®, LoviSil®) cable module (termination and installation set) |
| Certificates: | HD 628, HD 629 (CENELEC), IEC EN 61442, IEEE 404 |
| Dimensions KB85 (L/ø): | 1.280 x 305 mm |
| Dimensions KB95 (L/ø): | 1.500 x 320 mm |
| Customized solutions: | on request |
Types of cable joints
| Rated Voltage | Type of Joint | Type of Cable | Conductor Cross Section [mm²] |
Conductor Cross Section Crossed Conductor [mm²] |
Max. Outer Cable Diameter [mm] |
|---|---|---|---|---|---|
| 12 kV | M85 | polymeric/paper (1-core) polymeric (1 x 3-core) polymeric (3 x 1-core) paper (1 x 3-core) |
95 – 1000 70 – 240 70 – 240 70 – 240 |
not applicable 95 – 185 not applicable 95 – 185 |
82 82 38 82 |
| 12 kV | M95 | polymeric (1 x 3-core) polymeric (3 x 1-core) paper (1 x 3-core) |
120 – 300 120 – 300 120 – 300 |
150 – 240 not applicable 150 – 240 |
87 40 87 |
| 24 kV | M95 | polymeric/paper (1-core) polymeric (3 x 1-core) paper (1 x 3-core) |
95 – 1000 120 – 300 120 – 300 |
not applicable not applicable 240 |
87 40 87 |
| 36 kV | M95 | polymeric/paper (1-core) | 95 – 1000 | not applicable | 87 |
