Newcap MS
Cable Glands
Newcap MS
| Application: | non armored and braided cables in standard-/ Ex industry |
| Connection thread: | metric |
| Sizes: | M 12, 16, 20, 25, 32, 40, 50, 63 x 1,5 |
| Sealing range: | metric von ø 4 – 53 mm |
| Protection class: | IP 66, IP 68* 3 bar (30 m / 7 days) |
| Operating temperature: | -20 °C to +80 °C |
| Material Sealing insert: | neoprene |
| Material O-ring: | Perbunan |
| Material: | brass, stainless steel AISL 316L |
| Surface treatment: | nature, nickel plated |
| Explosion protection: | Ex II 2 GD Ex eb IIC / Ex nRc IIC / Ex tb IIIC Zone 1 and 2 group IIC Zone 21 and 22 group IIIC |
* Tested on a cable with a surface roughness of max. Ra 1.6 μm
Cable Gland Executions
| Article Number | Size | Connection Thread |
Sealing Range Outer Sheath [mm] |
Braid Thickness [mm] |
SW1/SW2 | L [mm] |
H [mm] |
PU |
|---|---|---|---|---|---|---|---|---|
| ap00192124V1 | 4 | M 12 x 1,5 | 4,0 – 6,5 | 0,70 | 15/15 | 6,5 | 18,0 | loose |
| ap00192154V1 | 4 | M 16 x 1,5 | 4,0 – 6,5 | 0,70 | 15/18 | 6,5 | 18,0 | loose |
| ap00192164V1 | 5 | M 16 x 1,5 | 5,5 – 10,0 | 0,70 | 20/20 | 6,5 | 24,0 | loose |
| ap00192194V1 | 5 | M 20 x 1,5 | 5,5 – 10,0 | 0,70 | 20/22 | 6,5 | 24,0 | loose |
| ap00192204V1 | 6 | M 20 x 1,5 |
7,5 – 13,0 |
0,80 | 24/24 | 6,5 | 27,0 | loose |
| ap00192244V1 | 6 | M 25 x 1,5 |
7,5 – 13,0 |
0,80 | 24/27 | 7,0 | 27,0 | loose |
| ap00192254V1 | 7 | M 25 x 1,5 |
11,5 – 18,0 |
0,85 | 30/30 | 7,0 | 28,0 | loose |
| ap00192314V1 | 7 | M 32 x 1,5 |
11,5 – 18,0 |
0,85 | 30/34 | 8,0 | 28,0 | loose |
| ap00192324V1 | 8 | M 32 x 1,5 |
17,5 – 24,5 |
0,95 | 38/38 | 8,0 | 30,0 | loose |
| ap00192394V1 | 8 | M 40 x 1,5 |
17,5 – 24,5 |
0,95 | 38/43 | 8,0 | 30,0 | loose |
| ap00192404V1 | 9 | M 40 x 1,5 |
24,0 – 32,0 |
1,0 | 47/47 | 8,0 | 33,0 | loose |
| ap00192494V1 | 9 | M 50 x 1,5 |
24,0 – 32,0 |
1,0 | 47/54 | 9,0 | 33,0 | loose |
| ap00192504V1 | 10 | M 50 x 1,5 |
31,0 – 40,5 |
1,15 | 57/57 | 9,0 | 37,0 | loose |
| ap00192624V1 | 10 | M 63 x 1,5 |
31,0 – 40,5 |
1,15 | 57/68 | 10,0 | 37,0 | loose |
| ap00192634V1 | 11 | M 63 x 1,5 |
39,0 – 53,0 |
1,75 | 75/75 | 10,0 | 48,0 | loose |
| Article Number | Size | Connection Thread |
Sealing Range Outer Sheath [mm] |
Braid Thickness [mm] |
SW1/SW2 | L [mm] |
H [mm] |
PU |
|---|---|---|---|---|---|---|---|---|
| ap00192129V1 | 4 | M 12 x 1,5 | 4,0 – 6,5 | 0,70 | 15/15 | 15,0 | 18,0 | loose |
| ap00192159V1 | 4 | M 16 x 1,5 | 4,0 – 6,5 | 0,70 | 15/18 | 15,0 | 18,0 | loose |
| ap00192169V1 | 5 | M 16 x 1,5 | 5,5 – 10,0 | 0,70 | 20/20 | 15,0 | 24,0 | loose |
| ap00192199V1 | 5 | M 20 x 1,5 | 5,5 – 10,0 | 0,70 | 20/22 | 15,0 | 24,0 | loose |
| ap00192209V1 | 6 | M 20 x 1,5 |
7,5 – 13,0 |
0,80 | 24/24 | 15,0 | 27,0 | loose |
| ap00192249V1 | 6 | M 25 x 1,5 |
7,5 – 13,0 |
0,80 | 24/27 | 15,0 | 27,0 | loose |
| ap00192259V1 | 7 | M 25 x 1,5 |
11,5 – 18,0 |
0,85 | 30/30 | 15,0 | 28,0 | loose |
| ap00192319V1 | 7 | M 32 x 1,5 |
11,5 – 18,0 |
0,85 | 30/34 | 15,0 | 28,0 | loose |
| ap00192329V1 | 8 | M 32 x 1,5 |
17,5 – 24,5 |
0,95 | 38/38 | 15,0 | 30,0 | loose |
| ap00192399V1 | 8 | M 40 x 1,5 |
17,5 – 24,5 |
0,95 | 38/43 | 15,0 | 30,0 | loose |
| ap00192409V1 | 9 | M 40 x 1,5 |
24,0 – 32,0 |
1,0 | 47/47 | 15,0 | 33,0 | loose |
| ap00192499V1 | 9 | M 50 x 1,5 |
24,0 – 32,0 |
1,0 | 47/54 | 15,0 | 33,0 | loose |
| ap00192509V1 | 10 | M 50 x 1,5 |
31,0 – 40,5 |
1,15 | 57/57 | 15,0 | 37,0 | loose |
| ap00192629V1 | 10 | M 63 x 1,5 |
31,0 – 40,5 |
1,15 | 57/68 | 15,0 | 37,0 | loose |
| ap00192639V1 | 11 | M 63 x 1,5 |
39,0 – 53,0 |
1,75 | 75/75 | 15,0 | 48,0 | loose |
