ADE 1F2
Cable Glands
ADE 1F2
| Application: | non armored cables, marine shipboard type P cables |
| Connection thread: | metric, NPT |
| Sizes: | M 12, 16, 20, 25, 32, 40, 50, 63, 75 x 1,5 M 90, 110 x 2 NPT ¼“, ⅜“, ½“, ¾“, 1“, 1 ¼“ NPT 1 ½“, 2“, 2 ½“, 3“, 3 ½“, 4“ |
| Sealing range: | metric from ø 4,5 – 104 mm NPT from ø 4,5 – 104 mm |
| Protection class: | IP 64, IP 66, IP 68* 3 bar (30 m / 7 days) |
| Operating temperature: | silicone: -60 °C to +140 °C neoprene: -30 °C to +80 °C |
| Material: | brass, stainless steel AISL 316L |
| Surface treatment: | nature, nickel plated |
| Explosion protection: | Ex II 2 GD Ex db IIC / Ex eb IIC / Ex tb IIIC zone 1 and 2 group IIA, IIB and IIC zone 21 and 22 group IIIA, IIIB and IIIC |
* Only with the use of a flat O-ring
Cable Gland Executions
| Article Number | Size | Connection Thread |
Sealing Range Outer Sheath [mm] |
SW1/SW2 | L [mm] |
H [mm] |
PU |
|---|---|---|---|---|---|---|---|
| ap00806404V1* | 4 | M 12 x 1,5 | 4,5 – 8,0 | 17/17 | 15,0 | 25,0 | loose |
| ap00806594V1* | 4 | M 16 x 1,5 | 4,5 – 8,5 | 17/19 | 15,0 | 25,0 | loose |
| ap00806504V1* | 5 | M 16 x 1,5 | 7,0 – 12,0 | 19/19 | 15,0 | 27,5 | loose |
| ap00806664V1 | 3 | M 20 x 1,5 | 2,8 – 5,5 | 15/24 | 15,0 | 24,0 | loose |
| ap00806674V1 | 4 | M 20 x 1,5 |
4,5 – 8,5 |
17/24 | 15,0 | 25,0 | loose |
| ap00806694V1 | 5 | M 20 x 1,5 |
7,0 – 12,0 |
19/24 | 15,0 | 27,5 | loose |
| ap00806604V1 | 6 | M 20 x 1,5 |
10,0 – 16,0 |
24/24 | 15,0 | 32,0 | loose |
| ap00806774V1 | 5 | M 25 x 1,5 |
7,0 – 12,0 |
19/30 | 15,0 | 27,5 | loose |
| ap00806794V1 | 6 | M 25 x 1,5 |
10,0 – 16,0 |
24/30 | 15,0 | 32,0 | loose |
| ap00806704V1 | 7 | M 25 x 1,5 |
13,5 – 20,5 |
30/30 | 15,0 | 36,5 | loose |
| ap00806804V1 | 8 | M 32 x 1,5 |
18,0 – 27,5 |
41/41 | 15,0 | 46,0 | loose |
| ap00806994V1 | 8 | M 40 x 1,5 |
18,0 – 27,5 |
48/48 | 15,0 | 50,0 | loose |
| ap00806904V1 | 9 | M 40 x 1,5 |
23,0 – 34,0 |
48/48 | 15,0 | 50,0 | loose |
| ap00807004V1 | 10 | M 50 x 1,5 |
29,0 – 41,0 |
55/55 | 16,0 | 52,0 | loose |
| ap00807084V1 | 11 | M 50 x 1,5 |
35,0 – 45,0 |
64/64 | 16,0 | 56,5 | loose |
| ap00807204V1 | 12 | M 63 x 1,5 |
42,0 – 56,0 |
72/72 | 17,0 | 60,0 | loose |
| ap00807304V1 | 13 | M 75 x 1,5 |
50,0 – 65,0 |
85/85 | 18,0 | 67,5 | loose |
| ap00807594V1 | 14 | M 90 x 2,0 |
58,0 – 74,0 |
95/95 | 22,0 | 69,0 | loose |
| ap00807504V1 | 15 | M 90 x 2,0 |
66,0 – 83,0 |
110/110 | 22,0 | 80,0 | loose |
| ap00807604V1 | 16 | M 110 x 2,0 |
75,0 – 93,0 |
120/120 | 22,0 | 80,0 | loose |
| ap00807704V1 | 17 | M 110 x 2,0 |
85,0 – 104,0 |
135/135 | 22,0 | 90,0 | loose |
* not UL certified
| Article Number | Size | Connection Thread |
Sealing Range Outer Sheath [mm] |
SW1/SW2 | L [mm] |
H [mm] |
PU |
|---|---|---|---|---|---|---|---|
| ap00806409V1* | 4 | M 12 x 1,5 | 4,5 – 8,0 | 17/17 | 15,0 | 25,0 | loose |
| ap00806599V1* | 4 | M 16 x 1,5 | 4,5 – 8,5 | 17/19 | 15,0 | 25,0 | loose |
| ap00806509V1* | 5 | M 16 x 1,5 | 7,0 – 12,0 | 19/19 | 15,0 | 27,5 | loose |
| ap00806669V1 | 3 | M 20 x 1,5 | 2,8 – 5,5 | 15/24 | 15,0 | 24,0 | loose |
| ap00806679V1 | 4 | M 20 x 1,5 |
4,5 – 8,5 |
17/24 | 15,0 | 25,0 | loose |
| ap00806699V1 | 5 | M 20 x 1,5 |
7,0 – 12,0 |
19/24 | 15,0 | 27,5 | loose |
| ap00806609V1 | 6 | M 20 x 1,5 |
10,0 – 16,0 |
24/24 | 15,0 | 32,0 | loose |
| ap00806779V1 | 5 | M 25 x 1,5 |
7,0 – 12,0 |
19/30 | 15,0 | 27,5 | loose |
| ap00806799V1 | 6 | M 25 x 1,5 |
10,0 – 16,0 |
24/30 | 15,0 | 32,0 | loose |
| ap00806709V1 | 7 | M 25 x 1,5 |
13,5 – 20,5 |
30/30 | 15,0 | 36,5 | loose |
| ap00806809V1 | 8 | M 32 x 1,5 |
18,0 – 27,5 |
41/41 | 15,0 | 46,0 | loose |
| ap00806999V1 | 8 | M 40 x 1,5 |
18,0 – 27,5 |
48/48 | 15,0 | 50,0 | loose |
| ap00806909V1 | 9 | M 40 x 1,5 |
23,0 – 34,0 |
48/48 | 15,0 | 50,0 | loose |
| ap00807009V1 | 10 | M 50 x 1,5 |
29,0 – 41,0 |
55/55 | 16,0 | 52,0 | loose |
| ap00807089V1 | 11 | M 50 x 1,5 |
35,0 – 45,0 |
64/64 | 16,0 | 56,5 | loose |
| ap00807209V1 | 12 | M 63 x 1,5 |
42,0 – 56,0 |
72/72 | 17,0 | 60,0 | loose |
| ap00807309V1 | 13 | M 75 x 1,5 |
50,0 – 65,0 |
85/85 | 18,0 | 67,5 | loose |
| ap00807599V1 | 14 | M 90 x 2,0 |
58,0 – 74,0 |
95/95 | 22,0 | 69,0 | loose |
| ap00807509V1 | 15 | M 90 x 2,0 |
66,0 – 83,0 |
110/110 | 22,0 | 80,0 | loose |
| ap00807609V1 | 16 | M 110 x 2,0 |
75,0 – 93,0 |
120/120 | 22,0 | 80,0 | loose |
| ap00807709V1 | 17 | M 110 x 2,0 |
85,0 – 104,0 |
135/135 | 22,0 | 90,0 | loose |
* not UL certified
| Article Number | Size | Connection Thread |
Sealing Range Outer Sheath [mm] |
SW1/SW2 | L [mm] |
H [mm] |
PU |
|---|---|---|---|---|---|---|---|
| ap00808404V1* | 4 | NPT 1/4″ | 4,5 – 8,0 | 17/17 | 16,6 | 25,0 | loose |
| ap00808594V1* | 4 | NPT 3/8″ | 4,5 – 8,5 | 17/19 | 16,6 | 27,5 | loose |
| ap00808504V1* | 5 | NPT 3/8″ | 7,0 – 12,0 | 19/19 | 16,6 | 27,5 | loose |
| ap00808664V1 | 3 | NPT 1/2″ | 2,8 – 5,5 | 15/24 | 22,2 | 24,0 | loose |
| ap00808674V1 | 4 | NPT 1/2″ |
4,5 – 8,5 |
17/24 | 22,2 | 25,0 | loose |
| ap00808694V1 | 5 | NPT 1/2″ |
7,0 – 12,0 |
19/24 | 22,2 | 27,5 | loose |
| ap00808604V1 | 6 | NPT 1/2″ |
10,0 – 16,0 |
24/24 | 22,2 | 32,0 | loose |
| ap00808774V1 | 5 | NPT 3/4″ |
7,0 – 12,0 |
19/30 | 22,2 | 27,5 | loose |
| ap00808794V1 | 6 | NPT 3/4″ |
10,0 – 16,0 |
24/30 | 22,2 | 32,0 | loose |
| ap00808704V1 | 7 | NPT 3/4″ |
13,5 – 20,5 |
30/30 | 22,5 | 36,5 | loose |
| ap00808804V1 | 8 | NPT 1″ |
18,0 – 27,5 |
41/41 | 27,3 | 46,0 | loose |
| ap00808904V1 | 9 | NPT 1 1/4″ |
23,0 – 34,0 |
48/48 | 28,0 | 50,0 | loose |
| ap00809004V1 | 10 | NPT 1 1/2″ |
29,0 – 41,0 |
55/55 | 28,5 | 52,0 | loose |
| ap00809084V1 | 11 | NPT 2″ |
35,0 – 45,0 |
64/64 | 29,2 | 56,5 | loose |
| ap00809204V1 | 12 | NPT 2″ |
42,0 – 56,0 |
72/72 | 29,2 | 60,0 | loose |
| ap00809304V1 | 13 | NPT 2 1/2″ |
50,0 – 65,0 |
85/85 | 42,5 | 67,5 | loose |
| ap00809594V1 | 14 | NPT 3″ |
58,0 – 74,0 |
95/95 | 44,0 | 69,0 | loose |
| ap00809504V1 | 15 | NPT 3″ |
66,0 – 83,0 |
110/110 | 44,0 | 80,0 | loose |
| ap00809604V1 | 16 | NPT 3 1/2″ |
75,0 – 93,0 |
120/120 | 34,2 | 80,0 | loose |
| ap00809704V1 | 17 | NPT 4″ |
85,0 – 104,0 |
135/135 | 46,5 | 90,0 | loose |
| Article Number | Size | Connection Thread |
Sealing Range Outer Sheath [mm] |
SW1/SW2 | L [mm] |
H [mm] |
PU |
|---|---|---|---|---|---|---|---|
| ap00808409V1* | 4 | NPT 1/4″ | 4,5 – 8,0 | 17/17 | 16,6 | 25,0 | loose |
| ap00808599V1* | 4 | NPT 3/8″ | 4,5 – 8,5 | 17/19 | 16,6 | 27,5 | loose |
| ap00808509V1* | 5 | NPT 3/8″ | 7,0 – 12,0 | 19/19 | 16,6 | 27,5 | loose |
| ap00808669V1 | 3 | NPT 1/2″ | 2,8 – 5,5 | 15/24 | 22,2 | 24,0 | loose |
| ap00808679V1 | 4 | NPT 1/2″ |
4,5 – 8,5 |
17/24 | 22,2 | 25,0 | loose |
| ap00808699V1 | 5 | NPT 1/2″ |
7,0 – 12,0 |
19/24 | 22,2 | 27,5 | loose |
| ap00808609V1 | 6 | NPT 1/2″ |
10,0 – 16,0 |
24/24 | 22,2 | 32,0 | loose |
| ap00808779V1 | 5 | NPT 3/4″ |
7,0 – 12,0 |
19/30 | 22,2 | 27,5 | loose |
| ap00808799V1 | 6 | NPT 3/4″ |
10,0 – 16,0 |
24/30 | 22,2 | 32,0 | loose |
| ap00808709V1 | 7 | NPT 3/4″ |
13,5 – 20,5 |
30/30 | 22,5 | 36,5 | loose |
| ap00808809V1 | 8 | NPT 1″ |
18,0 – 27,5 |
41/41 | 27,3 | 46,0 | loose |
| ap00808909V1 | 9 | NPT 1 1/4″ |
23,0 – 34,0 |
48/48 | 28,0 | 50,0 | loose |
| ap00809009V1 | 10 | NPT 1 1/2″ |
29,0 – 41,0 |
55/55 | 28,5 | 52,0 | loose |
| ap00809089V1 | 11 | NPT 2″ |
35,0 – 45,0 |
64/64 | 29,2 | 56,5 | loose |
| ap00809209V1 | 12 | NPT 2″ |
42,0 – 56,0 |
72/72 | 29,2 | 60,0 | loose |
| ap00809309V1 | 13 | NPT 2 1/2″ |
50,0 – 65,0 |
85/85 | 42,5 | 67,5 | loose |
| ap00809599V1 | 14 | NPT 3″ |
58,0 – 74,0 |
95/95 | 44,0 | 69,0 | loose |
| ap00809509V1 | 15 | NPT 3″ |
66,0 – 83,0 |
110/110 | 44,0 | 80,0 | loose |
| ap00809609V1 | 16 | NPT 3 1/2″ |
75,0 – 93,0 |
120/120 | 34,2 | 80,0 | loose |
| ap00809709V1 | 17 | NPT 4″ |
85,0 – 104,0 |
135/135 | 46,5 | 90,0 | loose |
* not UL certified
