Verschlussschraube mit Innensechskant
Gehäuse
Verschlussschraube mit Innensechskant
| Anwendung: | Standard- und Ex-Industrie |
| Anschlussgewinde: | Metrisch, NPT |
| Größen: | M 16, 20, 25, 32, 40, 50, 63 x 1,5 NPT 1“, 1 ½“, 1 ¼“, ½“, 2“, 2 ½“, ¾“ |
| Schutzklasse: | IP 68* 3 bar (30 m / 7 Tage) |
| Material: | Messing, Edelstahl 1.4404 |
| Oberflächenbehandlung: | Natur, vernickelt |
| Explosionsschutz: | Ex II 2 G D / Ex d IIC Gb / Ex e IIC G Ex tb IIIC Db |
| USP: | Kein O-Ring erforderlich |
* Nur mit der Verwendung einer Flachdichtung
Verschlussschrauben-Ausführungen
| Artikelnummer | Gewinde | Innensechskant | D [mm] |
L [mm] |
VPE |
|---|---|---|---|---|---|
| apCQA1100Y | M 16 x 1,5 | 6 | 20,0 | 15,0 | 1 |
| apCQA1200Y | M 20 x 1,5 | 10 | 25,0 | 15,0 | 1 |
| apCQA1300Y | M 25 x 1,5 | 10 | 30,0 | 15,0 | 1 |
| apCQA1400Y | M 32 x 1,5 | 10 | 38,0 | 15,0 | 1 |
| apCQA1500Y | M 40 x 1,5 |
19 | 46,0 | 15,0 | 1 |
| apCQA1600Y | M 50 x 1,5 |
19 | 57,0 | 15,0 | 1 |
| apCQA1700Y | M 63 x 1,5 |
19 | 70,0 | 15,0 | 1 |
| Artikelnummer | Gewinde | Innensechskant | D [mm] |
L [mm] |
VPE |
|---|---|---|---|---|---|
| apCQA1100YXN | M 16 x 1,5 | 6 | 20,0 | 15,0 | 1 |
| apCQA1200YXN | M 20 x 1,5 | 10 | 25,0 | 15,0 | 1 |
| apCQA1300YXN | M 25 x 1,5 | 10 | 30,0 | 15,0 | 1 |
| apCQA1400YXN | M 32 x 1,5 | 10 | 38,0 | 15,0 | 1 |
| apCQA1500YXN | M 40 x 1,5 |
19 | 46,0 | 15,0 | 1 |
| apCQA1600YXN | M 50 x 1,5 |
19 | 57,0 | 15,0 | 1 |
| apCQA1700YXN | M 63 x 1,5 |
19 | 70,0 | 15,0 | 1 |
| Artikelnummer | Gewinde | Innensechskant | D [mm] |
L [mm] |
VPE |
|---|---|---|---|---|---|
| apCQE1100Y | M 16 x 1,5 | 6 | 20,0 | 15,0 | 1 |
| apCQE1200Y | M 20 x 1,5 | 10 | 25,0 | 15,0 | 1 |
| apCQE1300Y | M 25 x 1,5 | 10 | 30,0 | 15,0 | 1 |
| apCQE1400Y | M 32 x 1,5 | 10 | 38,0 | 15,0 | 1 |
| apCQE1500Y | M 40 x 1,5 |
19 | 46,0 | 15,0 | 1 |
| apCQE1600Y | M 50 x 1,5 |
19 | 57,0 | 15,0 | 1 |
| apCQE1700Y | M 63 x 1,5 |
19 | 70,0 | 15,0 | 1 |
| Artikelnummer | Gewinde | Innensechskant | D [mm] |
L [mm] |
VPE |
|---|---|---|---|---|---|
| apCQA4200Y | NPT 1/2″ | 10 | 27,0 | 20,2 | 1 |
| apCQA4300Y | NPT 3/4″ | 10 | 32,0 | 20,5 | 1 |
| apCQA4400Y | NPT 1″ | 10 | 40,0 | 25,3 | 1 |
| apCQA4500Y | NPT 1 1/4″ | 19 | 50,0 | 26,0 | 1 |
| apCQA4600Y | NPT 1 1/2″ |
19 | 54,0 | 26,5 | 1 |
| apCQA4700Y | NPT 2″ |
19 | 67,0 | 27,2 | 1 |
| apCQA4800Y | NPT 2 1/2″ |
19 | 83,0 | 40,5 | 1 |
| Artikelnummer | Gewinde | Innensechskant | D [mm] |
L [mm] |
VPE |
|---|---|---|---|---|---|
| apCQA4200YXN | NPT 1/2″ | 10 | 27,0 | 20,2 | 1 |
| apCQA4300YXN | NPT 3/4″ | 10 | 32,0 | 20,5 | 1 |
| apCQA4400YXN | NPT 1″ | 10 | 40,0 | 25,3 | 1 |
| apCQA4500YXN | NPT 1 1/4″ | 19 | 50,0 | 26,0 | 1 |
| apCQA4600YXN | NPT 1 1/2″ |
19 | 54,0 | 26,5 | 1 |
| apCQA4700YXN | NPT 2″ |
19 | 67,0 | 27,2 | 1 |
| apCQA4800YXN | NPT 2 1/2″ |
19 | 83,0 | 40,5 | 1 |
| Artikelnummer | Gewinde | Innensechskant | D [mm] |
L [mm] |
VPE |
|---|---|---|---|---|---|
| apCQE4200Y | NPT 1/2″ | 10 | 27,0 | 20,2 | 1 |
| apCQE4300Y | NPT 3/4″ | 10 | 32,0 | 20,5 | 1 |
| apCQE4400Y | NPT 1″ | 10 | 40,0 | 25,3 | 1 |
| apCQE4500Y | NPT 1 1/4″ | 19 | 50,0 | 26,0 | 1 |
| apCQE4600Y | NPT 1 1/2″ |
19 | 54,0 | 26,5 | 1 |
| apCQE4700Y | NPT 2″ |
19 | 67,0 | 27,2 | 1 |
| apCQE4800Y | NPT 2 1/2″ |
19 | 83,0 | 40,5 | 1 |
